PHP RFC: Fibers

Introduction

For most of PHP’s history, people have written PHP code only as synchronous code. They have code that runs synchronously and in turn, only calls functions that run synchronously. Synchronous functions stop execution until a result is available to return from the function.

More recently, there have been multiple projects that have allowed people to write asynchronous PHP code. Asynchronous functions accept a callback or return a placeholder for a future value (such as a promise) to run code at a future time once the result is available. Execution continues without waiting for a result. Examples of these projects are amphp, ReactPHP, and Guzzle.

The problem this RFC seeks to address is a difficult one to explain, but can be referred to as the “What color is your function?” problem.

A summary of the problem described in the linked article is:

  • Asynchronous functions change the way the function must be called.
  • Synchronous functions may not call an asynchronous function (though asynchronous functions may call synchronous functions).
  • Calling an asynchronous function requires the entire callstack to be asynchronous

For people who are familiar with using promises and await/yield to achieve writing asynchronous code, the problem can be expressed as: “Once one function returns a promise somewhere in your call stack, the entire call stack needs to return a promise because the result of the call cannot be known until the promise is resolved.”

This RFC seeks to eliminate the distinction between synchronous and asynchronous functions by allowing functions to be interruptible without polluting the entire call stack. This would be achieved by:

  • Adding support for Fibers to PHP.
  • Adding Fiber, FiberScheduler, and the corresponding reflection classes ReflectionFiber and ReflectionFiberScheduler.
  • Adding exception classes FiberError and FiberExit to represent errors.

Definition of terms

To allow better understanding of the RFC, this section defines what the names Fiber and FiberScheduler mean for the RFC being proposed.

Fibers

Fibers allow the creation of full-stack, interruptible functions that can be used to implement cooperative multitasking in PHP. These are also known as coroutines or green-threads.

Fibers pause the entire execution stack, so the direct caller of the function does not need to change how it invokes the function.

Execution may be interrupted anywhere in the call stack using Fiber::suspend() (that is, the call to Fiber::suspend() may be in a deeply nested function or not even exist at all).

Unlike stack-less Generators, each Fiber has its own call stack, allowing them to be paused within deeply nested function calls. A function declaring an interruption point (i.e., calling Fiber::suspend()) need not change its return type, unlike a function using yield which must return a Generator instance.

This proposal treats {main} as a fiber, allowing Fiber::suspend() to be called from the top-level context.

Fibers can be suspended in any function call, including those called from within the PHP VM, such as functions provided to array_map or methods called by foreach on an Iterator object.

Once suspended, execution of the fiber may be resumed with any value using Fiber->resume() or by throwing an exception into the fiber using Fiber->throw(). The value is returned (or exception thrown) from Fiber::suspend().

FiberScheduler

A FiberScheduler is able to start new fibers and resume suspended fibers. A fiber scheduler will generally act as an event loop, responding to events on sockets, timers, and deferred functions. When a fiber is suspended, execution switches into the fiber scheduler to await events or resume other suspended fibers.

Proposal

Fiber

A Fiber would be represented as class which would be defined in core PHP with the following signature:

final class Fiber
{
    /**
     * @param callable $callback Function to invoke when starting the fiber.
     */
    public function __construct(callable $callback) { }

    /**
     * Starts execution of the fiber. Returns when the fiber suspends or terminates.
     *
     * Must be called within {@see FiberScheduler::run()}.
     *
     * @param mixed ...$args Arguments passed to fiber function.
     *
     * @throw FiberError If the fiber is running or terminated.
     * @throw Throwable If the fiber callable throws an uncaught exception.
     */
    public function start(mixed ...$args): void { }

    /**
     * Resumes the fiber, returning the given value from {@see Fiber::suspend()}.
     * Returns when the fiber suspends or terminates.
     *
     * Must be called within {@see FiberScheduler::run()}.
     *
     * @param mixed $value
     *
     * @throw FiberError If the fiber is running or terminated.
     * @throw Throwable If the fiber callable throws an uncaught exception.
     */
    public function resume(mixed $value = null): void { }

    /**
     * Throws the given exception into the fiber from {@see Fiber::suspend()}.
     * Returns when the fiber suspends or terminates.
     *
     * Must be called within {@see FiberScheduler::run()}.
     *
     * @param Throwable $exception
     *
     * @throw FiberError If the fiber is running or terminated.
     * @throw Throwable If the fiber callable throws an uncaught exception.
     */
    public function throw(Throwable $exception): void { }

    /**
     * @return bool True if the fiber has been started.
     */
    public function isStarted(): bool { }

    /**
     * @return bool True if the fiber is suspended.
     */
    public function isSuspended(): bool { }

    /**
     * @return bool True if the fiber is currently running.
     */
    public function isRunning(): bool { }

    /**
     * @return bool True if the fiber has completed execution.
     */
    public function isTerminated(): bool { }

    /**
     * Returns the currently executing Fiber instance.
     *
     * Cannot be called within {@see FiberScheduler::run()}.
     *
     * @return Fiber The currently executing fiber.
     *
     * @throws FiberError Thrown if within {@see FiberScheduler::run()}.
     */
    public static function this(): Fiber { }

    /**
     * Suspend execution of the fiber, switching execution to the scheduler.
     *
     * The fiber may be resumed with {@see Fiber::resume()} or {@see Fiber::throw()}
     * within the run() method of the instance of {@see FiberScheduler} given.
     *
     * Cannot be called within {@see FiberScheduler::run()}.
     *
     * @param FiberScheduler $scheduler
     *
     * @return mixed Value provided to {@see Fiber::resume()}.
     *
     * @throws FiberError Thrown if within {@see FiberScheduler::run()}.
     * @throws Throwable Exception provided to {@see Fiber::throw()}.
     */
    public static function suspend(FiberScheduler $scheduler): mixed { }
}

A Fiber object is created using new Fiber(callable $callback) with any callable. The callable need not call Fiber::suspend() directly, it may be in a deeply nested call, far down the call stack (or perhaps never call Fiber::suspend() at all). The returned Fiber may be started within a FiberScheduler (discussed below) using Fiber->start(mixed ...$args) with a variadic argument list that is provided as arguments to the callable used when creating the Fiber.

Fiber::suspend() suspends execution of the current fiber and switches to a scheduler fiber created from the instance of FiberScheduler given. This will be discussed in further detail in the next section describing FiberScheduler.

Fiber::this() returns the currently executing Fiber instance. This object may be stored to be used at a later time to resume the fiber with any value or throw an exception into the fiber. The Fiber object should be attached to event watchers in the FiberScheduler instance (event loop), added to a list of pending fibers, or otherwise used to set up logic that will resume the fiber at a later time from the instance of FiberScheduler provided to Fiber::suspend().

A suspended fiber may be resumed in one of two ways:

  • returning a value from Fiber::suspend() using Fiber->resume()
  • throwing an exception from Fiber::suspend() using Fiber->throw()

FiberScheduler

final class FiberScheduler
{
    /**
     * @param callable $callback Function to invoke when starting the fiber scheduler.
     */
    public function __construct(callable $callback) { }

    /**
     * @return bool True if the fiber has been started.
     */
    public function isStarted(): bool { }

    /**
     * @return bool True if the fiber is suspended.
     */
    public function isSuspended(): bool { }

    /**
     * @return bool True if the fiber is currently running.
     */
    public function isRunning(): bool { }

    /**
     * @return bool True if the fiber has completed execution.
     */
    public function isTerminated(): bool { }
}

A FiberScheduler is able to start new fibers using Fiber->start() and resume fibers using Fiber->resume() and Fiber->throw(). In general, a fiber scheduler would be created using a callback that runs an event loop that responds to events on sockets, timers, and deferred functions.

When an instance of FiberScheduler is provided to Fiber::suspend(), execution switches to the the scheduler fiber, a fiber created from the callback provided to the FiberScheduler constructor. This scheduler fiber is suspended when resuming or starting a Fiber (that is, when calling Fiber->start(), Fiber->resume(), or Fiber->throw()) and again resumed when the same instance of FiberScheduler is provided to another call to Fiber::suspend(). It is expected the callback provided to FiberScheduler will not return until all pending events have been processed and any suspended fibers have been resumed. In practice this is not difficult, as the scheduler fiber is suspended when resuming a fiber and only re-entered upon a fiber suspending which will create more events in the scheduler.

If a scheduler completes (that is, returns from the callback provided to FiberScheduler) without resuming the suspended fiber, an instance of FiberError is thrown from the call to Fiber::suspend().

If the callback provided to FiberScheduler throws an exception, this results in an uncaught FiberExit exception and exits the script.

A fiber must be resumed from within the instance of FiberScheduler provided to Fiber::suspend(). Doing otherwise results in a fatal error. In practice this means that calling Fiber->resume() or Fiber->throw() must be within a callback registered to an event handled within the code provided as the FiberScheduler callback. Often it is desirable to ensure resumption of a fiber is asynchronous, making it easier to reason about program state before and after an event would resume a fiber. New fibers also must be started within a FiberScheduler (though the started fiber may use any scheduler within that fiber).

Fibers must be started and resumed within a fiber scheduler in order to maintain ordering of the internal fiber stack. Internally, a fiber may only switch to a new fiber, a suspended fiber, or suspend to the prior fiber. In essense, a fiber may be pushed or popped from the stack, but execution cannot move to within the stack. The fiber scheduler acts as a hub which may branch into another fiber or suspend to the main fiber. If a fiber were to attempt to switch to a fiber that is already running, the program will crash. Checks prevent this from happening, throwing an exception into PHP instead of crashing the VM.

If all references to an instance of FiberScheduler are destroyed before a script terminates, the fiber is treated like an unfinished fiber.

When a script ends, each scheduler fiber that has not been previously destroyed or terminated is resumed in reverse order of creation to complete unfinished tasks or free resources.

ReflectionFiber

ReflectionFiber is used to inspect executing fibers. A ReflectionFiber object can be created from any Fiber object, even if it has not been started or if it has been finished. This reflection class is similar to ReflectionGenerator.

class ReflectionFiber
{
    /**
     * @param Fiber $fiber Any Fiber object, including those that are not started or have
     *                     terminated.
     */
    public function __construct(Fiber $fiber) { }

    /**
     * @return string Current file of fiber execution.
     *
     * @throws ReflectionException If the fiber has not been started or has terminated.
     */
    public function getExecutingFile(): string { }

    /**
     * @return int Current line of fiber execution.
     *
     * @throws ReflectionException If the fiber has not been started or has terminated.
     */
    public function getExecutingLine(): int { }

    /**
     * @param int $options Same flags as {@see debug_backtrace()}.
     *
     * @return array Fiber backtrace, similar to {@see debug_backtrace()}
     *               and {@see ReflectionGenerator::getTrace()}.
     *
     * @throws ReflectionException If the fiber has not been started or has terminated.
     */
    public function getTrace(int $options = DEBUG_BACKTRACE_PROVIDE_OBJECT): array { }

    /**
     * @return bool True if the fiber has been started.
     */
    public function isStarted(): bool { }

    /**
     * @return bool True if the fiber is currently suspended.
     */
    public function isSuspended(): bool { }

    /**
     * @return bool True if the fiber is currently running.
     */
    public function isRunning(): bool { }

    /**
     * @return bool True if the fiber has completed execution (either returning or
     *              throwing an exception).
     */
    public function isTerminated(): bool { }
}

ReflectionFiberScheduler

ReflectionFiberScheduler is used to inspect the internal fibers created from objects implementing FiberScheduler after being used to suspend a fiber.

class ReflectionFiberScheduler extends ReflectionFiber
{
    /**
     * @param FiberScheduler $scheduler
     */
    public function __construct(FiberScheduler $scheduler) { }

    /**
     * @return FiberScheduler The instance used to create the fiber.
     */
    public function getScheduler(): FiberScheduler { }
}

Unfinished Fibers

Fibers that are not finished (do not complete execution) are destroyed similarly to unfinished generators, executing any pending finally blocks. Fiber::suspend() may not be invoked in a force-closed fiber, just as yield cannot be used in a force-closed generator. Fibers are destroyed when there are no references to the Fiber object. An exception to this is the {main} fiber, where removing all references to the Fiber object that resumes the main fiber will result in a FiberExit exception to be thrown from the call to Fiber::suspend(), resulting in a fatal error.

Fiber Stacks

Each fiber is allocated a separate C stack and VM stack on the heap. The C stack is allocated using mmap if available, meaning physical memory is used only on demand (if it needs to be allocated to a stack value) on most platforms. Each fiber stack is allocated 1M maximum of memory by default, settable with an ini setting fiber.stack_size. Note that this memory is used for the C stack and is not related to the memory available to PHP code. VM stacks for each fiber are allocated in a similar way to generators and use a similar amount of memory and CPU. VM stacks are able to grow dynamically, so only a single VM page (4K) is initially allocated.

Backward Incompatible Changes

Declares Fiber, FiberScheduler, FiberError, FiberExit, ReflectionFiber, and ReflectionFiberScheduler in the root namespace. No other BC breaks.

Proposed PHP Version(s)

PHP 8.1

Future Scope

suspend keyword

Fiber::suspend() could be replaced with a keyword defining a statement where the body of the statement is executed before suspending the fiber, setting the Fiber instance to the variable name given and entering the FiberScheduler instance from the expression. (to should not need to be a keyword or reserved word, similar to from in yield from).

suspend ( variable to expression ) { statement(s) }

Below is an example usage of the proposed API inside an object method, where the current Fiber instance is added to an array before suspending, returning the value that resumes the fiber.

$this->waiting[$position] = Fiber::this();
return Fiber::suspend($scheduler);

The above could instead be written as the following using a suspend keyword.

return suspend ($fiber to $scheduler) {
    $this->waiting[$position] = $fiber;
}

async/await keywords

Using an internally defined FiberScheduler and an additionally defined Awaitable object, Fiber::suspend() could be replaced with the keyword await and new fibers could be created using the keyword async. The usage of async differs slightly from languages such as JS or Hack. async is not used to declare asynchronous functions, rather it is used at call time to modify the call to any function or method to return an awaitable and start a new fiber.

An Awaitable would act like a promise, representing the future result of the fiber created with async.

$awaitable = async functionOrMethod();
// async modifies the call to return an Awaitable, creating a new fiber, so execution continues immediately.
await $awaitable; // Await the function result at a later point.

These keywords can be created in user code using the proposed fiber API. amphp v3 (a work-in-progress) defines await() and async() functions to await Amp\Promise instances and create new coroutines.

defer keyword

Fibers may be used to implement a defer keyword that executes a statement within a new fiber when the current fiber is suspended or terminates. Such a keyword would also require an internal implementation of FiberScheduler and likely would be an addition after async/await keywords. This behavior differs from defer in Go, as PHP is already able to mimick such behavior with finally blocks.

This keyword also can be created in user code using the proposed fiber API, an example being defer() in amphp v3.

Proposed Voting Choices

Merge implementation into core, 2/3 required.

Patches and Tests

Implementation and tests at amphp/ext-fiber.

amphp v3, a work-in-progress, uses ext-fiber. Nearly all libraries under the GitHub organization amphp have branches compatible with amphp v3. The branches are labeled as vX, where X is the current version + 1 (for example, the v5 branch of amphp/http-client). See the examples directories in various libraries for samples of PHP code using fibers.

React Fiber uses ext-fiber and the current stable versions of react/event-loop and react/promise to create coroutines and await any instance of React\Promise\PromiseInterface until it is resolved.

Examples

First let’s define a very simple scheduler class which will be used by our first examples to create a FiberScheduler to demonstrate how fibers are suspended and resumed. This scheduler is only able to defer a function to execute at a later time. These functions are executed in a loop within EventLoop->run().

class EventLoop
{
    private array $callbacks = [];

    /**
     * Run the scheduler.
     */
    public function run(): void
    {
        while (!empty($this->callbacks)) {
            $callbacks = $this->callbacks;
            $this->callbacks = [];
            foreach ($callbacks as $id => $callback) {
                $callback();
            }
        }
    }

    /**
     * Enqueue a callback to executed at a later time.
     */
    public function defer(callable $callback): void
    {
        $this->callbacks[] = $callback;
    }
}

This scheduler does nothing really useful by itself, but will be used to demonstrate the basics of how a fiber may be suspended and later resumed in a fiber scheduler (event loop) upon an event.

$loop = new EventLoop;
$scheduler = new FiberScheduler(fn() => $loop->run());

// Get a reference to the currently executing fiber ({main} in this case).
$fiber = Fiber::this();

// This example defers a function that immediately resumes the fiber.
// Usually a fiber will be resumed in response to an event.

// Create an event in the fiber scheduler to resume the fiber at a later time.
$loop->defer(function () use ($fiber): void {
    // Fibers must be resumed within FiberScheduler::run().
    // This closure will be executed within the loop in Scheduler::run().
    $fiber->resume("Test");
});

// Suspend the main fiber, which will be resumed later by the scheduler.
$value = Fiber::suspend($scheduler);

echo "After resuming main fiber: ", $value, "\n"; // Output: After resuming main fiber: Test

This example is expanded for clarity and comments, but may be condensed using short closures.

$loop = new EventLoop;
$scheduler = new FiberScheduler(fn() => $loop->run());

$fiber = Fiber::this();
$loop->defer(fn() => $fiber->resume("Test"));
$value = Fiber::suspend($scheduler);

echo "After resuming main fiber: ", $value, "\n"; // Output: After resuming main fiber: Test

Fibers may also be resumed by throwing an exception.

$loop = new EventLoop;
$scheduler = new FiberScheduler(fn() => $loop->run());

// Get a reference to the currently executing fiber ({main} in this case).
$fiber = Fiber::this();

// This example instead throws an exception into the fiber to resume it.

// Create an event in the fiber scheduler to throw into the fiber at a later time.
$loop->defer(function () use ($fiber): void {
    $fiber->throw(new Exception("Test"));
});

try {
    // Suspend the main fiber, but this time it will be resumed with a thrown exception.
    $value = Fiber::suspend($scheduler);
    // The exception is thrown from the call to Fiber::suspend().
} catch (Exception $exception) {
    echo $exception->getMessage(), "\n"; // Output: Test
}

Again this example may be condensed using short closures.

$loop = new EventLoop;
$scheduler = new FiberScheduler(fn() => $loop->run());

$fiber = Fiber::this();
$loop->defer(fn() => $fiber->throw(new Exception("Test")));

try {
    $value = Fiber::suspend($scheduler);
} catch (Exception $exception) {
    echo $exception->getMessage(), "\n"; // Output: Test
}

To be useful, rather than the scheduler immediately resuming the fiber, the scheduler should resume a fiber at a later time in response to an event. The next example demonstrates how a scheduler can resume a fiber in response to data becoming available on a socket.


The next example adds to the event loop the ability to poll a socket for incoming data, invoking a callback when data becomes available on the socket. This scheduler can now be used to resume a fiber only when data becomes available on a socket, avoiding a blocking read.

class EventLoop
{
    private string $nextId = 'a';
    private array $deferCallbacks = [];
    private array $read = [];
    private array $streamCallbacks = [];

    public function run(): void
    {
        while (!empty($this->deferCallbacks) || !empty($this->read)) {
            $defers = $this->deferCallbacks;
            $this->deferCallbacks = [];
            foreach ($defers as $id => $defer) {
                $defer();
            }

            $this->select($this->read);
        }
    }

    private function select(array $read): void
    {
        $timeout = empty($this->deferCallbacks) ? null : 0;
        if (!stream_select($read, $write, $except, $timeout, $timeout)) {
            return;
        }

        foreach ($read as $id => $resource) {
            $callback = $this->streamCallbacks[$id];
            unset($this->read[$id], $this->streamCallbacks[$id]);
            $callback($resource);
        }
    }

    public function defer(callable $callback): void
    {
        $id = $this->nextId++;
        $this->deferCallbacks[$id] = $callback;
    }

    public function read($resource, callable $callback): void
    {
        $id = $this->nextId++;
        $this->read[$id] = $resource;
        $this->streamCallbacks[$id] = $callback;
    }
}

[$read, $write] = stream_socket_pair(
    stripos(PHP_OS, 'win') === 0 ? STREAM_PF_INET : STREAM_PF_UNIX,
    STREAM_SOCK_STREAM,
    STREAM_IPPROTO_IP
);

// Set streams to non-blocking mode.
stream_set_blocking($read, false);
stream_set_blocking($write, false);

$loop = new EventLoop;
$scheduler = new FiberScheduler(fn() => $loop->run());

// Read data in a separate fiber after checking if the stream is readable.
$fiber = new Fiber(function () use ($scheduler, $read): void {
    echo "Waiting for data...\n";

    $fiber = Fiber::this();
    $scheduler->read($read, fn() => $fiber->resume());
    Fiber::suspend($scheduler);

    $data = fread($read, 8192);

    echo "Received data: ", $data, "\n";
});

// Start the new fiber within the fiber scheduler.
$loop->defer(fn() => $fiber->start());

// Suspend main fiber to enter the scheduler.
$fiber = Fiber::this();
$loop->defer(fn() => $fiber->resume("Writing data...\n"));
echo Fiber::suspend($scheduler);

// Write data in main thread once it is resumed.
fwrite($write, "Hello, world!");

This script will output the following:

Waiting for data...
Writing data...
Received data: Hello, world!

If this example were written in a similar order without fibers, the script would be unable to read from a socket before writing to it, as the call to fread() would block until data was available.

Below is a chart illustrating execution flow between the three fibers in this example, {main}, the scheduler fiber, and the fiber created by new Fiber(). Execution flow switches between fibers as Fiber::suspend() and Fiber->resume() are called or when a fiber terminates.

Fiber execution flow


The next example below uses Loop from the ext-fiber tests, a simple event loop implemenation, yet more complex than that in the above examples, to delay execution of a function for 1000 milliseconds. When the fiber is suspended with Fiber::suspend(), resumption of the fiber is scheduled with Loop->delay(), which invokes the callback after the given number of milliseconds. An instance of FiberScheduler is returned from Loop::getScheduler().

$loop = new Loop;
$fiber = Fiber::this();
$loop->delay(1000, fn() => $fiber->resume(42));
var_dump(Fiber::suspend($loop->getScheduler())); // int(42)

This example can be expanded to create multiple fibers, each with it’s own delay before resuming.

$loop = new Loop;

// Create three new fibers and run them in the FiberScheduler.
$fiber = new Fiber(function () use ($loop): void {
    $fiber = Fiber::this();
    $loop->delay(1500, fn() => $fiber->resume(1));
    $value = Fiber::suspend($loop->getScheduler());
    var_dump($value);
});
$loop->defer(fn() => $fiber->start());

$fiber = new Fiber(function () use ($loop): void {
    $fiber = Fiber::this();
    $loop->delay(1000, fn() => $fiber->resume(2));
    $value = Fiber::suspend($loop->getScheduler());
    var_dump($value);
});
$loop->defer(fn() => $fiber->start());

$fiber = new Fiber(function () use ($loop): void {
    $fiber = Fiber::this();
    $loop->delay(2000, fn() => $fiber->resume(3));
    $value = Fiber::suspend($loop->getScheduler());
    var_dump($value);
});
$loop->defer(fn() => $fiber->start());

// Suspend the main thread to enter the FiberScheduler.
$fiber = Fiber::this();
$loop->delay(500, fn() => $fiber->resume(4));
$value = Fiber::suspend($loop->getScheduler());
var_dump($value);

The above code will output the following:

int(4)
int(2)
int(1)
int(3)

Total execution time for the script is 2 seconds (2000ms) as this is the longest delay (sleep) defined. A similar synchronous script would take 5 seconds to execute as each delay would be in series rather than concurrent.

While a contrived example, imagine if each of the fibers was awaiting data on a network socket or the result of a database query. Combining this with the ability to simultaneously run and suspend many fibers allows a single PHP process to concurrently await many events.


This example again uses Loop from the prior example. Similar to one of the previous examples, this one reads and writes to a socket, but takes a slightly different approach, performing the reading and writing within the fiber scheduler in response to the sockets having data available or space to write. The scheduler then resumes the fiber with the data or the number of bytes written. The example also waits 1 second before writing to the socket to simulate network latency.

[$read, $write] = stream_socket_pair(
    stripos(PHP_OS, 'win') === 0 ? STREAM_PF_INET : STREAM_PF_UNIX,
    STREAM_SOCK_STREAM,
    STREAM_IPPROTO_IP
);

// Set streams to non-blocking mode.
stream_set_blocking($read, false);
stream_set_blocking($write, false);

$loop = new Loop;

// Write data in a separate fiber after a 1 second delay.
$fiber = new Fiber(function () use ($loop, $write): void {
    $fiber = Fiber::this();

    // Suspend fiber for 1 second.
    echo "Waiting for 1 second...\n";
    $loop->delay(1000, fn() => $fiber->resume());
    Fiber::suspend($loop->getScheduler());

    // Write data to the socket once it is writable.
    echo "Writing data...\n";
    $loop->write($write, 'Hello, world!', fn(int $bytes) => $fiber->resume($bytes));
    $bytes = Fiber::suspend($loop->getScheduler());

    echo "Wrote {$bytes} bytes.\n";
});

$loop->defer(fn() => $fiber->start());

echo "Waiting for data...\n";

// Read data in main fiber.
$fiber = Fiber::this();
$loop->read($read, fn(?string $data) => $fiber->resume($data));
$data = Fiber::suspend($loop->getScheduler());

echo "Received data: ", $data, "\n";

The above code will output the following:

Waiting for data...
Waiting for 1 second...
Writing data...
Wrote 13 bytes.
Received data: Hello, world!

For simplicity this example is reading and writing to an internally connected socket, but similar code could read and write from many network sockets simultaneously.


The next few examples use the async framework amphp v3 mentioned in Patches and Tests to demonstrate how fibers may be used by frameworks to create asynchronous code that is written like synchronous code.

amphp v3 uses an event loop interface that extends FiberScheduler together with a variety of functions and a placeholder object (Promise) to build on top of the underlying fiber API to create its own opinionated API to create green-threads (coroutines) to execute code concurrently. Users of amphp v3 do not use the Fiber API directly, the framework handles suspending and creating fibers as necessary. Other frameworks may choose to approach creating green-threads and placeholders differently.

The defer(callable $callback, mixed ...$args) function creates a new fiber that is executed when the current fiber suspends or terminates. delay(int $milliseconds) suspends the current fiber until the given number of milliseconds has elasped.

This example is similar to the example above which created mutiple fibers that “slept” for differing times, but the underlying Fiber API is abstracted away into an API specific to the Amp framework. Note again this code is specific to amphp v3 and not part of this RFC, other frameworks may choose to implement this behavior in a different way.

use function Amp\defer;
use function Amp\delay;

// defer() creates a new fiber and starts it when the
// current fiber is suspended or terminated.
defer(function (): void {
    delay(1500);
    var_dump(1);
});

defer(function (): void {
    delay(1000);
    var_dump(2);
});

defer(function (): void {
    delay(2000);
    var_dump(3);
});

// Suspend the main fiber with delay().
delay(500);
var_dump(4);

The next example again uses amphp v3 to demonstrate how the FiberScheduler fiber continues executing while the main thread is suspended. The await(Promise $promise) function suspends a fiber until the given promise is resolved and the async(callable $callback, mixed ...$args) function creates a new fiber, returning a promise that is resolved when the fiber completes, allowing multiple fibers to be executed concurrently.

use function Amp\async;
use function Amp\await;
use function Amp\defer;
use function Amp\delay;

// Note that the function declares int as a return type, not Promise or Generator,
// but executes as a coroutine.
function asyncTask(int $id): int {
    // Nothing useful is done here, but rather acts as a substitute for async I/O.
    delay(1000); // Suspends the fiber this function executes within for 1 second.
    return $id;
}

$running = true;
defer(function () use (&$running): void {
    // This loop is to show how this fiber is not blocked by other fibers.
    while ($running) {
        delay(100);
        echo ".\n";
    }
});

// Invoking asyncTask() returns an int after 1 second, but is executed concurrently.
$result = asyncTask(1); // Call a subroutine within this fiber, taking 1 second to return.
var_dump($result);

// Simultaneously runs two new fibers, await their resolution in the main fiber.
// await() suspends the fiber until the given promise (or array of promises here) are resolved.
$result = await([  // Executed simultaneously, only 1 second will elapse during this await.
    async('asyncTask', 2), // async() creates a new fiber and returns a promise for the result.
    async('asyncTask', 3),
]);
var_dump($result); // Executed after 2 seconds.

$result = asyncTask(4); // Call takes 1 second to return.
var_dump($result);

// array_map() takes 2 seconds to execute as the two calls are not concurrent, but this shows
// that fibers are supported by internal callbacks.
$result = array_map('asyncTask', [5, 6]);
var_dump($result);

$running = false; // Stop the loop in the fiber created with defer() above.

Since fibers can be paused during calls within the PHP VM, fibers can also be used to create asynchronous iterators and generators. The example below uses amphp v3 to suspend a fiber within a generator, awaiting resolution of a Delayed, a promise-like object that resolves itself with the second argument after the number of milliseconds given as the first argument. When iterating over the generator, the foreach loop will suspend while waiting for another value to be yielded from the generator.

use Amp\Delayed;
use function Amp\await;

function generator(): Generator {
    yield await(new Delayed(500, 1));
    yield await(new Delayed(1500, 2));
    yield await(new Delayed(1000, 3));
    yield await(new Delayed(2000, 4));
    yield 5;
    yield 6;
    yield 7;
    yield await(new Delayed(2000, 8));
    yield 9;
    yield await(new Delayed(1000, 10));
}

// Iterate over the generator as normal, but the loop will
// be suspended and resumed as needed.
foreach (generator() as $value) {
    printf("Generator yielded %d\n", $value);
}

// Argument unpacking also can use a suspending generator.
var_dump(...generator());

The example below shows how ReactPHP might use fibers to define an await() function using their PromiseInterface and LoopInterface. (Note this example assumes LoopInterface would add a getScheduler() method returning an instance of FiberScheduler associated with the event loop instance.)

use React\EventLoop\LoopInterface;
use React\Promise\PromiseInterface;

function await(PromiseInterface $promise, LoopInterface $loop): mixed
{
    $fiber = Fiber::this();

    $promise->done(
        fn(mixed $value) => $loop->futureTick(fn() => $fiber->resume($value)),
        fn(Throwable $reason) => $loop->futureTick(fn() => $fiber->throw($reason))
    );

    return Fiber::suspend($loop->getScheduler());
}

A demonstration of integrating ReactPHP with fibers has been implemented in trowski/react-fiber for the current stable versions of react/event-loop and react/promise.


The final example uses the cURL extension to create a fiber scheduler based on curl_multi_exec() to perform multiple HTTP requests concurrently. When a new fiber is started, Scheduler->async() returns a Promise, a placeholder to represent the eventual result of the new fiber, which may be awaited later using Scheduler->await().

class Promise
{
    /** @var Fiber[] */
    private array $fibers = [];
    private Scheduler $scheduler;
    private bool $resolved = false;
    private ?Throwable $error = null;
    private mixed $result;

    public function __construct(Scheduler $scheduler)
    {
        $this->scheduler = $scheduler;
    }

    public function await(): mixed
    {
        if (!$this->resolved) {
            $this->schedule(Fiber::this());
            return Fiber::suspend($this->scheduler->getScheduler());
        }

        if ($this->error) {
            throw $this->error;
        }

        return $this->result;
    }

    public function schedule(Fiber $fiber): void
    {
        if ($this->resolved) {
            if ($this->error !== null) {
                $this->scheduler->defer(fn() => $fiber->throw($this->error));
            } else {
                $this->scheduler->defer(fn() => $fiber->resume($this->result));
            }

            return;
        }

        $this->fibers[] = $fiber;
    }

    public function resolve(mixed $value = null): void
    {
        if ($this->resolved) {
            throw new Error("Promise already resolved");
        }

        $this->result = $value;
        $this->continue();
    }

    public function fail(Throwable $error): void
    {
        if ($this->resolved) {
            throw new Error("Promise already resolved");
        }

        $this->error = $error;
        $this->continue();
    }

    private function continue(): void
    {
        $this->resolved = true;

        $fibers = $this->fibers;
        $this->fibers = [];

        foreach ($fibers as $fiber) {
            $this->schedule($fiber);
        }
    }
}

class Scheduler
{
    private FiberScheduler $scheduler;
    /** @var resource */
    private $curl;
    /** @var callable[] */
    private array $defers = [];
    /** @var Fiber[] */
    private array $fibers = [];

    public function __construct()
    {
        $this->curl = curl_multi_init();
    }

    public function __destruct()
    {
        curl_multi_close($this->curl);
    }

    public function getScheduler(): FiberScheduler
    {
        if (!isset($this->scheduler) || $this->scheduler->isTerminated()) {
            $this->scheduler = new FiberScheduler(fn() => $this->run());
        }

        return $this->scheduler;
    }

    public function fetch(string $url): string
    {
        $curl = curl_init();

        curl_setopt($curl, CURLOPT_URL, $url);
        curl_setopt($curl, CURLOPT_HEADER, 0);
        curl_setopt($curl, CURLOPT_RETURNTRANSFER, 1);

        curl_multi_add_handle($this->curl, $curl);

        $this->fibers[(int) $curl] = Fiber::this();
        Fiber::suspend($this->getScheduler());

        $status = curl_getinfo($curl, CURLINFO_RESPONSE_CODE);
        if ($status !== 200) {
            throw new Exception(sprintf('Request to %s failed with status code %d', $url, $status));
        }

        $body = substr(trim(curl_multi_getcontent($curl)), 0, 255);

        curl_close($curl);

        return $body;
    }

    public function defer(callable $callable): void
    {
        $this->defers[] = $callable;
    }

    public function async(callable $callable): Promise
    {
        $promise = new Promise($this);

        $fiber = new Fiber(function () use ($promise, $callable) {
            try {
                $promise->resolve($callable());
            } catch (Throwable $e) {
                $promise->fail($e);
            }
        });

        $this->defer(fn() => $fiber->start());

        return $promise;
    }

    public function run(): void
    {
        do {
            do {
                $defers = $this->defers;
                $this->defers = [];

                foreach ($defers as $callable) {
                    $callable();
                }

                $status = curl_multi_exec($this->curl, $active);
                if ($active) {
                    $select = curl_multi_select($this->curl);
                    if ($select > 0) {
                        $this->processQueue();
                    }
                }
            } while ($active && $status === CURLM_OK);

            $this->processQueue();
        } while ($this->defers);
    }

    private function processQueue(): void
    {
        while ($info = curl_multi_info_read($this->curl)) {
            if ($info['msg'] !== CURLMSG_DONE) {
                continue;
            }

            $fiber = $this->fibers[(int) $info['handle']];
            $fiber->resume();
        }
    }
}

function await(Promise ...$promises): array
{
    return array_map(fn($promise) => $promise->await(), $promises);
}

$urls = array_fill(0, $argv[1] ?? 10, 'https://amphp.org/');

$scheduler = new Scheduler;

$promises = [];
foreach ($urls as $url) {
    $promises[] = $scheduler->async(fn() => $scheduler->fetch($url));
}

print 'Starting to make ' . count($promises) . ' requests...' . PHP_EOL;

$start = hrtime(true);

$responses = await(...$promises);

// var_dump($responses);

print ((hrtime(true) - $start) / 1_000_000) . 'ms' . PHP_EOL;

FAQ

Who is the target audience for this feature?

Fibers are an advanced feature that most users will not use directly. This feature is primarily targeted at library and framework authors to provide an event loop and an asynchronous programming API. Fibers allow integrating asynchronous code execution seamlessly into synchronous code at any point without the need to modify the application call stack or add boilerplate code.

The Fiber API is not expected to be used directly in application-level code. Fibers provide a basic, low-level flow-control API to create higher-level abstractions that are then used in application code.

FFI is an example of a feature recently added to PHP that most users may not use directly, but can benefit from greatly within libraries they use.

Why use FiberScheduler instead of an API similar to Lua or Ruby?

Fibers require a scheduler to be useful. A scheduler is responsible for creating and resuming fibers. A fiber on it’s own does nothing – something external to the fiber must control it. This is not unlike generators. When you iterate over a generator using foreach, you are using a “scheduler” to control the generator. If you write code using the send() or throw() methods of a generator, you are writing a generator scheduler. However, because generators are stack-less and can only yield from their immediate context, the author of a generator has direct control over what is yielded within that generator.

Fibers may suspend deep within the call stack, usually within library code authored by another. Therefore it makes sense to move control of the scheduler used to the point of fiber suspension, rather than at fiber creation.

Additionally, using a fiber scheduler API enables a few features:

  • Suspension of the top-level ({main}): When the main fiber is suspended, execution continues into the fiber scheduler.
  • Nesting schedulers: A fiber may suspend into different fiber schedulers at various suspension points. Each scheduler will be started/suspended/resumed as needed. While a fully asynchronous app may want to ensure it does not use multiple fiber schedulers, a FPM application may find it acceptable to do so.
  • Elimination of boilerplate: Suspending at the top-level eliminates the need for an application to wrap code into a library-specific scheduler, allowing library code to suspend and resume as needed, without concern that the user used the appropriate scheduler that may conflict with another library’s scheduler.

The Fiber API is a low-level method of flow-control that is aimed at library and framework authors. A “simpler” API will not lead to average developers using fibers, will hurt interoperability, and require more work and complexity for the average developer to use any library using fibers.

What about performance?

Switching between fibers is lightweight, requiring changing the value of approximately 20 pointers, give or take, depending on platform. Switching execution context in the PHP VM is similar to Generators, again only requiring the swapping of a few pointers. Since fibers exist within a single process thread, switching between fibers is significantly more performant than switching between processes or threads.

What platforms are supported?

Fibers are supported on nearly all modern CPU architectures, including x86, x86_64, 32- and 64-bit ARM, 32- and 64-bit PPC, MIPS, Windows (architecture independent, Windows provides a fiber API), and older Posix platforms with ucontext. Support for C stack switching using assembly code is provided by Boost, which has an OSI-approved license that allows components to be distributed directly with PHP.

ext-fiber is actively tested on Travis for Linux running on x86_64 and 64-bit ARM, on AppVeyor for Windows, and by the developers on macOS running on x86_64.

How is a FiberScheduler callback implemented?

A FiberScheduler callback should invoke the necessary code to resume suspended fibers for the given application. Generally, a FiberScheduler would be created from a function that runs a loop through available events, resuming fibers when an event occurs. The ext-fiber repo contains a very simple implementation, Loop, that is able to delay functions for a given number of milliseconds or until the scheduler is entered again. This simple implementation is used in the ext-fiber tests.

How does blocking code affect fibers

Blocking code (such as file_get_contents()) will continue to block the entire process, even if other fibers exist. Code must be written to use asynchonous I/O, an event loop, and fibers to see a performance and concurrency benefit. As mentioned in the introduction, several libraries already exist for asynchronous I/O and can take advantage of fibers to integrate with synchronous code while expanding the potential for concurrency in an application.

As fibers allow transparent use of asynchronous I/O, blocking implementations can be replaced by non-blocking implementations without affecting the entire call stack. If an internal scheduler is available in the future, internal functions such as sleep() could be made non-blocking by default.

How do various fibers access the same memory?

All fibers exist within a single thread. Only a single fiber may execute at a time, so memory cannot be accessed or modified simultaneously by multiple fibers, unlike threads which may modify memory simultaneously.

As fibers are suspended and resumed, execution of multiple fibers that access the same memory can be interleaved. Thus a running fiber may modify memory depended upon by another suspended fiber. There are various strategies to address this problem, including mutexes, semaphores, memory parcels, and channels. This RFC does not provide any such implementations as these can be implemented in user space code using the proposed fiber API. Below is an example implementation of a mutex using the proposed fiber API and the example Loop implementation in the ext-fiber tests.

class Mutex
{
    private Loop $loop;
    private SplQueue $queue;
    private bool $locked = false;

    public function __construct(Loop $loop)
    {
        $this->loop = $loop;
        $this->queue = new SplQueue;
    }

    public function acquire(): Lock
    {
        if ($this->locked) {
            $this->queue->push(Fiber::this());
            Fiber::suspend($this->loop->getScheduler());
        }

        $this->locked = true;

        return new Lock(function (): void {
            if ($this->queue->isEmpty()) {
                $this->locked = false;
                return;
            }

            $fiber = $this->queue->pop();
            $this->loop->defer(fn() => $fiber->resume());
        });
    }
}

class Lock
{
    private \Closure $release;

    public function __construct(\Closure $release)
    {
        $this->release = $release;
    }

    public function __destruct()
    {
        $this->release();
    }

    public function release(): void
    {
        if (isset($this->release)) {
            $release = $this->release;
            unset($this->release);
            ($release)();
        }
    }
}

Why add this to PHP core?

Adding this capability directly in PHP core makes it widely available on any host providing PHP. Often users are not able to determine what extensions may be available in a particular hosting environment, are unsure of how to install extensions, or do not want to install 3rd-party extensions. With fibers in PHP core, any library author may use the feature without concerns for portability.

Extensions that profile code need to account for switching fibers when creating backtraces and calculating execution times. This needs to be provided as a core internal API so any profiler could support fibers. The internal API that would be provided is out of scope of this RFC as it would not affect user code.

Why not add an event loop and async/await API to core?

This RFC proposes only the bare minimum required to allow user code to implement full-stack coroutines or green-threads in PHP. There are several frameworks that implement their own event loop API, promises, and other asynchronous APIs. These APIs vary greatly and are opinionated, designed for a particular purpose, and their particular needs may not be able to be covered by a core API that is designed by only a few individuals.

It is the opinion of the authors of this RFC that it is best to provide the bare minimum in core and allow user code to implement other components as they desire. If the community moves toward a single event loop API or a need emerges for an event loop in PHP core, this can be done in a future RFC. Providing a core event loop without core functionality using it (such as streams, file access, etc.) would be misleading and confusing for users. Deferring such functionality to user frameworks and providing only a minimum API in core keeps expectations in check.

This RFC does not preclude adding async/await and an event loop to core, see Future Scope.

How does this proposal differ from prior Fiber proposals?

The prior Fiber RFC did not support context switching within internal calls (array_map, preg_replace_callback, etc.) or opcode handlers (foreach, yield from, etc.). This could result in a crash if a function using fibers was used in any user code called from C code or in extensions that override zend_execute_ex such as Xdebug.

The API proposed here also differs, allowing suspension of the main context.

Are fibers compatible with extensions, including Xdebug?

Fibers do not change how the PHP VM executes PHP code and suspending is supported within the C stack, so fibers are compatible with PHP extensions that simply provide a bridge to a C API, including those using callbacks that may call Fiber::suspend().

Some extensions hook into the PHP VM and therefore are of particular interest for compatibility.

  • Xdebug is compatible as of a bugfix in version 3.0.1. Breakpoints may be set within fibers and inspected as usual within IDEs and debuggers such as PhpStorm. Code coverage works as expected.
  • pcov generates code coverage as expected, including code executed within separate fibers.
  • parallel is able to use fibers within threads.

As noted in “Why add this to PHP core?”, extensions that profile code, create backtraces, provide execution times, etc. will need to be updated to account for switching between fibers to provide correct data.

References

rfc/fibers.txt · Last modified: 2021/01/06 21:10 by trowski
